IML Underwater Hull Light, for 12/24V AC or DC, MR16, 75W max (bulb not included),
Silicon Bronze, Clear Lens, IP68
|
The IML Underwater Hull Light is manufactured specifically for the purpose
of illuminating the marine environment around and/or underneath a ship's
hull. Perfect for fishing, diving or just plain entertainment.
Careful consideration has been made in the selection of materials and components
that make up this fixture. Its streamline bezel results in near zero
drag when installed in hull's bottom. The fixture is designed to work
with a 50W or 75W MR16 Halogen reflector lamp.
|
|
|
 |
The IML Underwater Thru-Hull Light is available in either silicon bronze
or 316 stainless
steel for utmost resistance against corrosion and electrolysis action.
This purpose built thru-hull underwater light is fully accessible from inside
the boat making bulb changes simple and fast without the hassle of hauling
the vessel.
Bulbs are not included.
Please select one of the following halogen lamps for use with this light:
ILGU5.3-12/75NL - GU5.3 MR16 Reflector Lamp (No Lens), 12V, 75W, Clear
ILGU5.3-24/75NL
- GU5.3 MR16 Reflector Lamp (No Lens), 24V, 75W, Clear
ILGU5.3-12/50
- GU5.3 MR16 Reflector Lamp (No Lens), 12V, 50W, Clear
ILGU5.3-24/50
- GU5.3 MR16 Reflector Lamp (No Lens), 24V, 50W, Clear
|
| Features & Benefits: |
- Machined Silicon Bronze body/lens bezel
- Low profile trim bezel for optimal hydrodynamics
- High temperature silicone inner o-ring seals
- Optional self-leveling mounting kit (includes floating clamp ring
and 4 set screws)
|
| Product Details |
| Finish: |
Silicon Bronze |
| Glass Lens: |
15mm tempered ground glass,
clear |
| Voltage: |
12/24V AC or DC |
| Socket: |
GU5.3 (MR16) |
| Lamp: |
50W or 75W max (sold separately) |
| Amp Draw: |
4.17A @ 12V, 2.08A @ 24V |
| Max. Hull Thickness: |
2.8" (71mm) |
| Max. Hull Thickness with Silicone Washer:
|
2.48" (63mm) |
| Cutout: |
3.13" (79.5mm) |
| IP Rating: |
IP68 |
| Wire Size: |
See Chart
|
| Weight: |
6.400 lbs. |
|
|
|
