Continuing on the success of the Lofrans Project 1000, the Lofrans Project 1500 is larger, accepts several chain and rope sizes, and is offered with multiple motor configurations. The Lofrans Project 1500 features contemporary styling with a robust, dual direction high torque series-wound motor. The marine grade chromed bronze is hand polished for a mirror-like finish.
Every engineering detail is designed for durable, long lasting performance. The corrosion-resistant, anodized aluminum sealed oil bath gearbox features a 70:1 gear ratio for fast, controlled deployment and recovery of the ground tackle system. The balanced clutch cone system engages and disengages easily for “free fall” or independent capstan operation. A locking nut is provided on low profile models as an added safety feature to help prevent accidental anchor deployment. Manual override is included as a standard feature, along with a nickel-plated chainwheel gypsy, watertight control box and two covered footswitches.
Project 1500 Windlass, Low Profile, 1500W, 24VDC, Chrome
Standard Equipment:
- Watertight dual-direction control box
- Two heavy duty covered footswitches
- Emergency override handle
- Rope/chain gypsy
- Neoprene deck gasket
Replaces Old Part #LW7941LP/1
|
|
| Product Details - LW7942LP/1 (Old part number LW7941LP/1) |
| Motor Wattage: |
1500W |
| Voltage: |
24VDC |
| Power Rating: |
1850 lbs |
| Amp Draw: |
50-70A |
| Retrieval Speed: |
60 ft/min |
| Chain Sizes: |
5/16HT & BBB, 3/8HT |
| Rope Sizes: |
5/8, 3/4 3-strand nylon |
| Standard Equipment: |
watertight dual-direction control box, two heavy duty covered footswitches, emergency override handle, rope/chain gypsy, neoprene deck gasket |
| Deck Thickness: |
1-15/16 in. to 2-3/4 in. (standard) |
| Weight: |
61.000 lbs. |
|
|
|
