Compact, Strong, Top Performance
The Quick Ultra Genius Windlass 1000 Series perfectly suit the requirements of those who have limited space below deck or on deck. The Quick Ultra Genius Windlass 1000 is compact and easy to install. An elegant solution to the problem of too little muscle power. The Ultra Genius 1000 is precision-machined to give you more muscle for your money than comparable units.
Each Quick Ultra Genius includes a reversible solenoid, a clutch handle and an owner's manual.
Available with or without rope drum.
Features:
- Rugged, high-strength, all-aluminum clear anodized housing
- Highly polished chrome-plated bronze rope/chain gypsy
- Poly-composite control arm with heavy-duty spring ensures smooth operation
- 40% faster retrieval than comparable windlasses at maximum load
- Choose from two gypsy sizes - 1/4" HT or 5/16" HT (specify at checkout)
- Clutch handle releases gypsy for manual freefall
- Power consumption is 30% to 50% less than comparable windlasses
- Permanent magnet motor and epicyclical (planetary) gears for maximum pull
- 3 year warranty
 For boats from 20 - 39 ft (6 to 12 m)
Ultra Genius 500W 20 - 30 ft (6 - 9 m)
Ultra Genius 800W 26 - 39 ft (8 - 12 m)
|
| Standard version |
Genius/FF 1000 / 1000 D |
| Motor power |
800 W |
| Motor supply voltage |
12 V |
| Maximum pull |
1983 lb |
| Maximum working load |
771 lb |
| Working load |
265 lb |
| Current absorbtion @ working load (1) |
85 A |
| Maximum chain speed (2) |
99 ft/min |
| Maximum chain speed @ working load (2) |
99 ft/min |
| Weight - Genius - [without drum] |
23 lb |
| Weight - Genius D - [with drum] |
25 lb |
| Weight - Genius FF |
24 lb |
| 1) |
After an initial period of use |
| 2) |
Measurements taken with a gypsy for a 8 mm chain |
|
 |
|
